MCB

Ensure the safety of your electrical systems with our high-quality MCBs. Manufactured in India, these miniature circuit breakers offer reliable protection against overloads and short circuits. Available in various ratings, they are suitable for residential, commercial, and industrial applications. Lntsufin.com offers a diverse range of MCBs from trusted sellers, ensuring quick delivery and competitive pricing.
L&T-SuFin is an integrated B2B marketplace for buying and selling industrial and construction products and services. Backed by India’s leading conglomerate, Larsen & Toubro, we are one of the leading b2b marketplaces in India. L&T-SuFin enables businesses, especially MSMEs, to source their industrial suppliers pan-India, digitally and cost-effectively.

Buy High-Quality MCB online at L&T-SuFin

What is MCB?

A miniature circuit breaker (MCB) is a type of electrical protection device that helps to protect electrical circuits in the event of an overload or short circuit. It is used in residential and commercial buildings to protect electrical systems from damage due to high currents. It is a form of electrical protection device similar to a fuse, but it is more efficient and reliable.

An MCB works by detecting an overload or short circuit and automatically disconnecting the power supply. This helps to prevent an electrical overload or short circuit that can cause a fire or damage electrical equipment. The MCB will then have to be manually reset when the fault is resolved.

MCBs are designed to be used in combination with other protective measures such as switches and surge protectors. Therefore, it is important to have a complete electrical protection system in place that incorporates all the necessary safety features.

The primary benefit of using an MCB is that it provides quick and efficient protection from electrical overloads and short circuits. This helps to minimize damage to electrical equipment and minimize the risk of an electrical fire. It also helps to reduce the chances of an unexpected power outage.

Overall, an MCB is an essential part of any electrical protection system. It is an efficient and reliable form of protection that helps to keep electrical systems and equipment safe.

Types of MCB in Indian Market

There are different types of MCBs available, each with its own characteristics and purpose. The most common types are Type B MCB, Type C MCB, Type D MCB, Type K MCB and Type Z MCB.

Type B MCBs

- Type B MCBs are the most basic type and are primarily used in residential installations. At a rate of three to five times its rated current, this type of MCB will instantaneously trip. They are designed to protect against overloads, and their tripping characteristics vary depending on the manufacturer. Type B MCBs are economical and easy to install and maintain, making them a popular choice for many residential applications.

Type C MCBs

- Type C MCBs are more complex than Type B, and they are used in both residential and commercial applications. At a rate of five to ten times its rated current, this type of MCB will instantaneously trip. They are designed to protect against overloads and short circuits, and they use a thermal-magnetic tripping mechanism. Type C MCBs are generally more expensive than Type B MCBs, but they offer increased protection and reliability.

Type D MCBs

- Type D MCBs are the most advanced type of MCB and are used in industrial applications. At a rate of ten to twenty-five times its rated current, this kind of tiny circuit breaker will trip immediately. They are designed to protect against both overloads and short circuits, and their tripping characteristics are very precise. Type D MCBs are usually the most expensive type of MCB, but they offer the highest level of protection and reliability.

Type K MCBs : When the current is between eight and twelve times the maximum advised value, these will trip. They are an excellent option for motors.

Type Z MCBs: These MCBs are extremely sensitive, tripping even when the current is just two or three times greater than the rated load. They are employed with more delicate, short-circuit-prone electronics like semiconductors.

In conclusion, MCBs come in different types, each with its own characteristics and purpose. Type B MCBs are the most basic and economical type, whereas Type D MCBs are the most advanced and expensive type. No matter which type you choose, MCBs are essential components of any electrical installation, and they provide essential protection against overloads and short circuits.

Types of MCBs (by Ampere Range) –

MCBs are rated according to their ampere range which are as follows:

0.5A, 1A, 2A, 3A, 4A, 5A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A and 63A.

No matter the ampere range of the MCB, it is important to ensure that the device is properly rated for the intended application. Selecting the wrong type of MCB can result in serious damage or injury due to electrical faults.

Uses of MCB –

MCB are used in electrical panels as circuit protection to prevent damage to valuable electrical components, lighting systems, and industrial equipment and applications.

The main purpose of MCB is to protect against over loads and short circuit to eliminate potential hazards. This is done by monitoring the current flowing through the circuit and tripping when the current exceeds a certain level. MCBs also provide the advantage of easy resetting, as they can be manually reset without having to turn off the main source of power and then turning it back on again.

MCBs are also used in sensitive electronic applications as they provide a very low level of contact resistance which can help prevent equipment breakdown due to voltage spikes. They are also used in power distribution systems where they are used to protect vulnerable electronic components from overloading or short-circuits.

MCBs are an essential part of any electrical system and are typically used in residential, commercial, and industrial applications. Not only do they provide an efficient way of protecting electrical systems, but they also help to minimize downtime in the event of an electrical fault. Therefore, MCBs are an essential component of any electrical system and are essential to electrical safety.

Top factors to consider before buying MCB –

When it comes to buying MCB (Miniature Circuit Breaker), there are a few important things to consider to ensure that you purchase the right type and size for your needs.

First and foremost, you must make sure that the MCB you purchase is rated to handle the amount of current your electrical system requires. The MCB must have a current rating that is higher than the circuit current it will be protecting.

It is also important to consider the type of MCB you need. There are different types of MCBs such as type B, type C, and type D. Depending on your specific requirements, you will need to choose the type of MCB that is best suited for your application.

In addition to selecting the right type of MCB, you must also consider the type of connector that is used to connect the MCB to the electrical system. MCBs typically use either screw or push-in connectors (i.e. DIN Rail mounting). Both types have their advantages and disadvantages, and the choice of connector should be based on the application.

Finally, it is important to make sure that the MCB you purchase is compatible with the electrical system it is being used with. You should ensure that the MCB is suitable for the voltage, frequency and number of phases of the system.

By taking into account these key factors, you can be sure that you purchase the right type of MCB for your needs.

Top Brands for MCB in India –

MCB (Miniature Circuit Breakers) are essential components of electrical and electronic systems. They are designed to protect the electrical circuit from short circuits and overloads, thus providing a high level of safety. In India, there are several popular brands of MCB, which provide a range of features and options.

Legrand MCB

Their RoHS Compliant MCBs are highly efficient and reliable, with features such as double break mechanism, trip indicator and ergonomic test button. These MCBs are RoHS compliant, meaning they are free from hazardous materials. The double break mechanism ensures quick disconnection of the circuit in case of an overload or fault, while the trip indicator gives an indication of the fault in the circuit. The ergonomic test button ensures that the MCB is always in good working condition.

Havells MCB

- Havells is another prominent brand of MCB in India, offering a range of products with features such as finger proof terminal, dual termination and true contact indication. The finger proof terminal prevents accidental contact with live parts, while the dual termination enables two MCBs to be connected to one circuit. The true contact indication ensures that the circuit is under control even in the case of a fault.

L&T MCB -

 Finally, L&T MCB offers MCBs with features such as finger proof terminal, dual termination and true contact indication. The finger proof terminal ensures maximum safety, while the dual termination enables two MCBs to be connected to one circuit. The true contact indication ensures that the circuit is under control even in the case of a fault.

In conclusion, MCB are an essential component of any electrical or electronic system, and the top brands in MCB in India offer a range of features and options. The brands discussed in this article are Legrand MCB, Havells MCB and L&T MCB, each offering their own unique features and advantages.

Top Selling MCB Price List in India

Brand	Model Name	Price (INR) (Incl of GST)
L&T	L&T BA10100C Single Pole 10 A C MCB	189.98
Schneider	Schneider Electric A9N1P06C Single Pole 6 A C MCB	161.75
SIEMENS	SIEMENS 5SL61066RC Single Pole 6 A B MCB	173.46
Pressfit	Pressfit 810105 Single Pole 6 A C MCB	106.2
RC Bentex	RC Bentex XC04000021 Single Pole 6 A C MCB	111.51

Price updated as on 13 Oct 2023.

Why to buy MCB online at L&T-SuFin

Empower your electrical systems with confidence! Purchase Miniature Circuit Breakers (MCBs) online at L&T-SuFin. Explore a diverse range from trusted suppliers, benefit from competitive prices, seamless logistics, and flexible business finance options. Upgrade your electrical safety effortlessly—buy MCBs on our B2B e-commerce platform.

Frequently asked questions about MCB -

1. What is a miniature circuit breaker (MCB)?

A miniature circuit breaker (MCB) is a device used to protect electrical systems from overloads and short circuits. It acts as a switch to turn off the electrical circuit when it senses an overload and helps to prevent fires resulting from overheated wiring. MCBs are typically installed in residential and commercial buildings and provide protection for a range of electrical circuits, from large appliances to small devices.

2. What are the features of an MCB?

MCBs are equipped with a range of features to ensure the protection of an electrical system. These features include adjustable tripping characteristics, short-circuit protection, thermal-magnetic operation, and overload protection. Additionally, MCBs are designed to work in different environments and are available in a variety of sizes and designs to meet the needs of various electrical systems.

3. How do miniature circuit breakers work?

MCBs work by monitoring the amount of current in an electrical circuit. If the current exceeds a predetermined limit set by the manufacturer, the MCB will trip, or turn off the electrical circuit, thus preventing an overload. This is done by a bimetallic strip within the device that senses the temperature of the current and trips when it reaches a certain threshold.

4. What are the benefits of using an MCB?

The most significant benefit of using an MCB is the protection it provides against electrical overloads and short circuits. An MCB can help to prevent fires due to overheated wiring and can also provide protection from dangerous electrical shocks. Additionally, MCBs are relatively easy to install and require minimal maintenance.

5. How do you choose the right MCB for an application?

The choice of MCB for an application depends on the specific requirements of the electrical system. Factors such as the type of circuit, the voltage and current ratings, the environment, and the type of protection required should all be taken into consideration when selecting an MCB. Additionally, it is important to check the manufacturer’s specifications to ensure the MCB is suitable for the intended application.

6. What are the types of MCBs available?

MCBs are available in a variety of designs, sizes and can be used in different environments. Common types of MCBs include thermal-magnetic. Additionally, some MCBs are specially designed for high-temperature applications or for use in harsh environments, such as those found in industrial application.
