A medium coated rutile electrode suitable for all position welding of Steel structures and tanks, truck frames and bodies, machinery construction, auto body frames, railway wagons, ships, pipelines, bridges etc.
Approvals:
BHEL Trichy, NTPC, LRS Gr 1, ABS Gr 1, DNV Gr 1, IRS Gr 1, BV Gr 1, BIS, IBR (CIB-Maharashtra), M.N. Dastur, MahaGenco.
CODING: E 6013, IS 814-ER 4211X
TYPICAL ALL WELD ANALYSIS (%)
C: 0.10 max
Mn: 0.60 max
Si: 0.40 max
S: 0.03 max
P: 0.03 max
MECHANICAL PROPERTIES
UTS (N/mm2): 480-530
YS (N/mm2): 380-490
Elongation%: 22-26
Impact Value-CVN: 55-60J at 0°C
Read less
A medium coated rutile electrode suitable for all position welding of Steel structures and tanks, truck frames and bodies, machinery construction, auto body frames, railway wagons, ships, pipelines, bridges etc.
Approvals:
BHEL Trichy, NTPC, LRS Gr 1, ABS Gr 1, DNV Gr 1, IRS Gr 1, BV Gr 1, BIS, IBR (CIB-Maharashtra), M.N. Dastur, MahaGenco.
CODING: E 6013, IS 814-ER 4211X
TYPICAL ALL WELD ANALYSIS (%)
C: 0.10 max
Mn: 0.60 max
Si: 0.40 max
S: 0.03 max
P: 0.03 max
MECHANICAL PROPERTIES
UTS (N/mm2): 480-530
YS (N/mm2): 380-490
Elongation%: 22-26
Impact Value-CVN: 55-60J at 0°C
