TESA Surface Roughness Comparator

Small-size, versatile roughness tester providing maximum ease of use.  Measures up to 90 mm vertically without the need for a special support.  49 roughness parameters.  Measuring range of 50 mm in ...

Small-size, versatile roughness tester providing maximum ease of use.  Measures up to 90 mm vertically without the need for a special support.  49 roughness parameters.  Measuring range of 50 mm in the X axis.  Interchangeable probe, with or without contact skid.  Measures roughness parameters according to ISO 4287, 12085 (CNOMO), 13565, DIN 4776, JIS B0601:2001 and ASME B46-2002. Roughness Parameters: o DIN / ISO / JIS / ASME : Ra - Rq - Rt - Rp - Rc - Rv - RSm - Rδc - RPc - Pa - Pq -Pt - Pp - Pc - Pv - PSm - Pδc – PPc - Wa - Wq - Wt - Wz - Wp - Wv - Wc - WSm – Wδc – WPc - Rmr - Rz – Rmax - Rsk - Rku – Wz - Rk - Rpk - Rvk - Mr1 - Mr2 o DB N31007 : R3z - R3zm o MOTIF ISO 12085 (CNOMO): Pt - R - Rx - AR - Wte - W - AW - Wx – Rke - Rpke - Rvke - Pdc - PPc - Mr1e - Mr2e Graphics: Profile-W, Profile-R, Profile-P, Bearing Area Curve  Cut-off Length: 0.08 – 0.25 – 0.80 – 2.50 – 8.00 mm  Number of Cut-off: o 1 to 19 for a cut-off upto 2.5 mm; o 1 to 5 for cut-off of 8.00 mm
