e-Brix EB-6008 8 Port 100 Mbps IP40 Ethernet Switch

The EB‑6008 is an 8‑port unmanaged industrial Ethernet switch engineered for stable and efficient network expansion in demanding environments. It supports 8×10/100Base‑TX RJ45 ports with auto‑negotiati...

The EB‑6008 is an 8‑port unmanaged industrial Ethernet switch engineered for stable and efficient network expansion in demanding environments. It supports 8×10/100Base‑TX RJ45 ports with auto‑negotiation and MDI/MDI‑X capability. Designed with a fanless, low‑power architecture and IP40 aluminum alloy housing, it operates reliably from ‑20°C to +75°C with strong EMC protection. The switch offers 1.6Gbps backplane bandwidth, store‑and‑forward switching, 1K MAC table, and <10µs latency. With DC12–57V dual power redundancy, reverse polarity protection, and over‑current protection, it is suitable for industrial automation, transportation, surveillance, smart lighting, and utility applications.

8×10/100M RJ45 ports, IP40 aluminum housing, ‑20°C to +75°C, DC12–57V input, fanless cooling, EMC‑rated, store‑and‑forward, auto MDI/MDI‑X.
